Whyte 9x8 Multiswitch WM908

The Whyte Series 9 range comes fitted with Pro-Tap™ Technology. Developed by Whyte Technologies, a Pro-Tap is an in-built “Protean Tap” which enables the installer to easily select input tap losses of 0,-10 or -20dB, whilst still maintaining a trunk through loss of only 4dB.

IRS System pre-planning is virtually not required as tap loss settings are selected at the commissioning stage

› Separate SAT and TERR Pro-Taps™ for ease of installation
› Comes with Earth Bars fitted
› Use as standalone when powered with a Whyte PSU
› SAT gain 10dB / TERR gain 8dB
› Gain Control on all inputs
› Comes with 9 F-Type couplers for easy connection to Series 9 Multiswitches, Splitters and LaunchAmplifiers
› Uses receiver power to reduce demands on PSU
› Colour coded inputs and outputs
› LED Power Indicator and Inbuilt LTE filter
› Cables can be routed under the multiswitch
